š§ Extreme Performance: Supports AMD Ryzenā¢ Threadripperā¢ PRO 9000/7000 WX-Series & 9000/7000 Series CPUs with 18+3+3 Power Phase and 110A SPS for VCore
ā” Next-Gen Expansion: Features 3 PCIe 5.0 x16 slots, 2 PCIe 4.0 x16, and Blazing M.2 Gen5 for ultra-fast GPU and SSD performance
š§¬ ECC DDR5 Memory: Supports up to 1TB Quad Channel DDR5 ECC RDIMM memory with speeds up to 7600+ MHz (OC)
š Ultimate Connectivity: Equipped with Marvell 10GbE LAN, Realtek 2.5GbE LAN, and Wi-Fi 6E + Bluetooth for seamless networking
š„ Server-Grade Build: 12-layer PCB with 2oz copper, composite VRM heatsinks, and Hi-Density power connectors for stability and durability
š§ Immersive Audio: Realtek ALC1220 7.1 CH HD Audio with Nahimic enhancements for crystal-clear sound and gaming immersion
The ASRock TRX50 WS is a high-end workstation motherboard designed for professionals who demand top-tier performance and reliability. Built to support AMD Ryzenā¢ Threadripperā¢ PRO 9000/7000 series processors, it features ECC DDR5 memory, PCIe 5.0 slots, and blazing-fast M.2 storage. With 10GbE LAN, Wi-Fi 6E, and server-grade durability, itās ideal for rendering, simulation, and AI workloads. Whether you're building a workstation or a deep learning rig, this board delivers uncompromised power and stability.
Product Specifications:
| Specification | Details |
| Brand | ASRock |
| Model | TRX50 WS |
| Chipset | AMD TRX50 |
| Socket | sTR5 |
| Form Factor | EATX (30.5 cm x 27.7 cm) |
| Memory Support | 4 x DDR5 RDIMM ECC, up to 1TB, 7600+ MHz (OC) |
| Expansion Slots | 3 x PCIe 5.0 x16, 2 x PCIe 4.0 x16 |
| Storage Options | 1 x Blazing M.2 (Gen5), 1 x Hyper M.2 (Gen4), 1 x MCIO, 2 x SlimSAS, 4 x SATA3 |
| Audio | Realtek ALC1220 7.1 CH HD Audio, Nahimic Audio |
| Networking | Marvell 10GbE LAN, Realtek 2.5GbE LAN, Wi-Fi 6E + Bluetooth |
| USB Ports | USB 3.2 Gen2x2 Type-C, USB 3.2 Gen2 Type-A/C, USB 3.2 Gen1, USB 2.0 |
| RGB Support | Polychrome RGB with addressable headers |
| Power Design | 18+3+3 Phase, 110A SPS, Hi-Density Connectors |
| Cooling | Composite VRM Heatsink with active cooling |
| Country of Origin | Taiwan |
| Model Number | TRX50 WS |
| Warranty | 3 Years |
| Weight | 1.8 kg |
