Specifications
| Category | Details |
|---|---|
| CPU |
LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU * Please refer to "CPU Support List" for more information. |
| Chipset | Intel H610 Express Chipset |
| Memory |
Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules 2 × DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 (non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 Support for Extreme Memory Profile (XMP) (Refer to "Memory Support List" for more information.) |
| Onboard Graphics |
Integrated Graphics Processor – Intel HD Graphics 1 × D-Sub port (max 1920×1200 @ 60 Hz) 1 × HDMI port (max 4096×2160 @ 60 Hz) * Supports HDMI 2.1 and HDCP 2.3 ** Native HDMI 2.1 TMDS compatible (Graphics specs vary depending on CPU) |
| Audio |
Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel support Configurable via audio software for 7.1-channel output |
| LAN | Intel GbE LAN (1 Gbps / 100 Mbps) |
| Expansion Slots |
1 × PCI Express x16 slot (PCIe 4.0) * Install GPU in PCIEX16 slot for best performance 1 × PCI Express x1 slot (PCIe 3.0) |
| Storage Interface |
1 × M.2 connector (Socket 3, M key, 2260/2280 PCIe 3.0 x4/x2 SSD) 4 × SATA 6Gb/s connectors |
| USB |
Chipset: - 4 × USB 3.2 Gen 1 (2 rear, 2 internal) - 4 × USB 2.0/1.1 (rear) Chipset + USB 2.0 Hub: - 4 × USB 2.0/1.1 (internal) |
| Internal I/O |
1 × 24-pin ATX power connector 1 × 8-pin ATX 12V power connector 1 × M.2 Socket 3 4 × SATA 6Gb/s connectors 1 × CPU fan header 2 × system fan headers 1 × RGB LED strip header 1 × front panel header 1 × front audio header 1 × USB 3.2 Gen 1 header 2 × USB 2.0/1.1 headers 1 × TPM header 1 × serial port header 1 × Clear CMOS jumper |
| Back Panel |
1 × PS/2 keyboard port 1 × PS/2 mouse port 1 × D-Sub port 1 × HDMI 2.0 port 2 × USB 3.2 Gen 1 ports 4 × USB 2.0/1.1 ports 1 × RJ-45 LAN port 3 × audio jacks |
| I/O Controller | iTE I/O Controller Chip |
| H/W Monitoring |
Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Supported features depend on cooler installed |
| BIOS |
1 × 256 Mbit flash AMI UEFI BIOS Supports PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
Support for APP Center @BIOS Ambient LED EasyTune Smart Backup System Information Viewer Support for Q-Flash Support for Xpress Install |
| Bundled Software |
Norton Internet Security (OEM) LAN bandwidth management software |
| Operating System |
Windows 11 64-bit Windows 10 64-bit |
| Form Factor | Micro ATX, 23.0cm × 21.5cm |
