Specifications
| Specification | Details |
|---|---|
| PFC Type | Active PFC |
| Dimensions | 16 x 15 x 8.6 Centimeter |
| Efficiency | 80Plus Gold |
| MTBF | >120,000 hrs @ 25°C |
| Protection Features | OPP / OVP / UVP / SCP / OCP / OTP |
| Hazardous Materials | ROHS |
| AC Input Range | 100-240Vac |
| RGB Connector | NA |
| Fan Size | 135mm |
| DC Output Voltage | +3.3V, +5V, +12V, -12V, +5Vsb |
| Maximum Load | 20A, 20A, 62A, 0.3A, 3A |
| Total Output | 750W |
| Cable Connectors |
MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 6+2-pin x 4 SATA x 8 Peripheral x 3 |
| Package Contents |
Power Cord x1 Motherboard Power Cable x1 (610mm) CPU Cable x2 (1000mm) PCIE 1-to-2 Cable x2 (675+75mm) SATA 1-to-4 Cable x1 (410+150+150+150mm) SATA 1-to-4 Cable x1 (450+120+120+120mm) Peripheral 1-to-3 Cable x1 (450+120+120mm) Join the ROG badge x2 ROG logo magnet x1 ROG label x3 *MB / CPU / PCI-E cables come with embedded capacitors in the middle. |
| Cybenetics Noise Level Certification | NA |
| 0dB Technology | Supported — Fan shuts off under certain load |
