Specifications:
|
Product Name |
MWE Bronze 650 V3 230V |
|
Item Code |
MPE-6501-ACABW-3BIN |
|
ATX Version |
ATX 12V Ver. 3.1 |
|
PFC |
Active PFC |
|
Input Voltage |
200 - 240V |
|
Input Current |
5A |
|
Input Frequency |
50 - 60Hz |
|
Dimensions (L x W x H) |
140 x 150 x 86mm |
|
Fan Size |
120 mm |
|
Fan Bearing |
HDB |
|
Efficiency |
≥ 88% @ Typical Load |
|
80 PLUS Rating |
80 PLUS Bronze |
|
ErP 2014 Lot 3 |
Yes |
|
Operating Temperature |
0 ~ 40℃ |
|
Power Good Signal |
100 - 150ms |
|
Hold Up Time |
≥ 16ms |
|
MTBF |
>100,000 hours @ 25℃ ambient |
|
Protections |
UVP / OVP / OPP / OTP / SCP |
|
Regulatory |
TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.) |
|
Connectors |
ATX 24 Pin: x1 = 1x (500mm) EPS 8Pin / 4+4 Pin: x2 = 1x (550+120mm) SATA: x6 = 2x (400+150+150mm) Peripheral 4 Pin: x3 = 1x (400+150+150mm) PCI-e 6+2 Pin: x4 = 2x (500+120mm) |
|
Weight |
Net: 1.65 kg Gross: 2.05 kg |
|
Package Dimensions |
245 x 190 x 110mm (9.65 x 7.48 x 4.33") |
|
Warranty |
5 years |
