Technical Specs:
| Product Dimensions | 116×147×164 mm(L×W×H) |
| Heatsink Dimensions | 140×110×160 mm(L×W×H) |
| Net Weight | 1380 g |
| Heatpipe | Ø6 mm×7 pcs |
| Fan Dimensions | 140×140×25 mm(L×W×H) |
| Fan Speed (Performance Mode) | 500~1800 RPM±10% |
| Fan Airflow (Performance Mode) | 61.25 CFM |
| Fan Air Pressure (Performance Mode) | 3.76 mmAq |
| Overall Noise (Performance Mode) | ≤29.3 dB(A) |
| Fan Speed (Quiet Mode) | 500~1450 RPM±10% |
| Fan Airflow (Quiet Mode) | 48.55 CFM |
| Fan Air Pressure (Quiet Mode) | 2.46 mmAq |
| Overall Noise (Quiet Mode) | ≤22.6 dB(A) |
| Fan Connector | 4-pin PWM |
| Bearing Type | Fluid Dynamic Bearing |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.2 A |
| Fan Power Consumption | 2.4 W |
| Rated Voltage | 12 VDC |
| Power Consumption(Performance Mode) | 3.6 W |
| Power Consumption(Quiet Mode) | 2.4 W |
| EAN | 6933412728702 |
| P/N | R-ASN4S-WHGPMN-G |
