SPECIFICATIONS
| MACUBE 550 WH is designed to present a modern and concise look. Novel functional designs like hidden air inlets and a magnetic glass panel help eliminate the unnecessary and keeps everything simple. |
Technical Spec
| Motherboards | Mini-ITX/Micro-ATX/ATX?MAX 305*276mm? |
| Materials |
ABS+SGCC+Tempered Glass+Aluminum Plate |
| 5.25" Drive Bays |
0 |
| 3.5" Drive Bays |
4 |
| 2.5" Drive Bays |
3 |
| I/O Panel |
2â—ŠUSB3.0/Audioâ—Š1/Micâ—Š1 |
| Expansion Slots |
8+2 Slots |
| Cooling Fans Support |
Pre-installed: Rear: 1â—Š120mm DC fan; Optional: Front: 3â—Š120mm; Side: 3x120mm/3x140mm |
| Power Supply Type |
ATX PS2 (maximum length: 170mm) |
| CPU Cooler Height Limit |
186mm |
| CPU Cooler Compatibility |
Front: 120/240/360mm; Side: 120/140/240/280/360mm ; Rear: 120/140mm |
| Graphic Card Clearance |
310mm Horizontal/420mm Vertical |
| Cable Management |
25mm clearance |
| EAN |
6933412713821 |
| P/N |
GS-ATX-MACUBE550-WHG0P |
