Specifications
| Category | Specification |
|---|---|
| GPU | NVIDIA® GeForce RTX™ 5070 Ti |
| CUDA Cores | 8960 |
| Architecture | Blackwell |
| Base Clock | 2295 MHz |
| Boost Clock | 2452 MHz |
| Memory Size | 16GB GDDR7 |
| Memory Clock | 28 Gbps |
| Memory Interface | 256-bit |
| Memory Bandwidth | 896 GB/sec |
| Bus Interface | PCI Express Gen 5 |
| DirectX Support | DirectX 12 Ultimate |
| OpenGL Support | OpenGL 4.6 |
| Vulkan API | 1.4 |
| Ray Tracing | Yes (4th Gen RT Cores, 133 TFLOPS) |
| Tensor Cores | 5th Gen, 1406 AI TOPS |
| DLSS Version | 4 |
| Display Outputs | 3x DisplayPort 2.1b1x HDMI 2.1b |
| Maximum Resolution | 4K @ 480Hz or 8K @ 165Hz with DSC |
| Multi-Monitor Support | Up to 4 |
| HDCP Support | 2.3 |
| G-SYNC™ Support | Yes |
| Power Consumption | 250W |
| Recommended PSU | 750W |
| Power Connectors | 2x PCIe 8-pin (adapter included) OR PCIe Gen 5 (12V-2x6, 300W+) |
| NVIDIA Features | Ansel, FreeStyle, ShadowPlay, Highlights, GPU Boost™, Game Ready & Studio Drivers |
| Encoder / Decoder | 2x Ninth Gen Encoder, 1x Sixth Gen Decoder |
| Supported OS | Windows 11 / 10 (64-bit, v1809+), Linux, FreeBSDx86 |
| Card Dimensions (L×H×W) | 300 × 116 × 41 mm |
| Form Factor | ATX |
| Slot Size | 2-slot |
| Accessories Included | VGA Manual12V-2x6 to 2x PCIe 8-pin AdapterVGA Holder + Manual |
| Warranty | 3 Years |
