Specifications
| Category | Specification |
|---|---|
| GPU Engine Specs | |
| Graphics Processing | GeForce RTX™ 5070 |
| Architecture | Blackwell |
| CUDA Cores | 6144 |
| Base Clock | 2325 MHz |
| Boost Clock | 2542 MHz |
| NVIDIA GPU Boost™ | Yes |
| Memory Specs | |
| Memory Size | 12 GB |
| Memory Type | GDDR7 |
| Memory Clock | 28 Gbps |
| Memory Interface Width | 192-bit |
| Memory Bandwidth | 672 GB/sec |
| Power & Thermal | |
| Minimum System Power | 650W |
| Power Connectors | 2x PCIe 8-pin (adapter in box) OR 300W+ PCIe Gen 5 cable |
| Bus & Interface | |
| Bus Standard | PCI Express Gen 5 |
| PCB Form Factor | ATX |
| Display & Output | |
| Standard Display Outputs | 3x DisplayPort 2.1b, 1x HDMI 2.1b |
| Maximum Digital Resolution | 4K @ 480Hz or 8K @ 165Hz (with DSC) |
| Multi-Monitor Support | Up to 4 |
| HDCP | 2.3 |
| Feature Support | |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| Vulkan API | 1.4 |
| Real-Time Ray Tracing | Yes (4th Gen RT Cores, 94 TFLOPS) |
| Tensor Cores | 5th Gen, 988 AI TOPS |
| DLSS Version | 4 |
| NVIDIA Ansel | Yes |
| NVIDIA FreeStyle | Yes |
| NVIDIA ShadowPlay | Yes |
| NVIDIA Highlights | Yes |
| G-SYNC™ Ready | Yes |
| Game Ready Drivers | Yes |
| Studio Drivers | Yes |
| NVIDIA Encoder | 1x Ninth Generation |
| NVIDIA Decoder | 1x Sixth Generation |
| OS Compatibility | Windows 11 / 10, Linux, FreeBSDx86 |
| Physical Specs | |
| Card Dimensions (L×H×W) | 300 × 116 × 41 mm |
| Accessories | 1x Quick Guide 1x 12V-2x6 to 2x PCIe 8-pin Adapter |
| Warranty | 3 Years |
