About This Product
Enhance your conference calls with the 360° All Around Webcam. This all-in-one virtual meeting device combines HD video with business-grade audio clarity, to help run your video conferences smoothly. This high-definition, plug-and-play webcam, is ideal for any space. Capture a 360° panoramic view of the room or focus on specific presenters with the various display modes. The 360° All Around Webcam is equipped with a USB-C® cable and a USB™ Type-A connector to work with both your older and newer devices.
For the best image quality, we recommend downloading the JVCU360 firmware update from our downloads page which you can navigate to by clicking here.
Key Features
• 360° video conferencing camera
• Built-in omnidirectional microphone
• Six display modes deliver exceptional viewing angles with flexibility and versatility
• Adjustable fields of view
• Full HD 1080p video playback @ 30 Hz
• USB™ UVC plug-and-play
• Touch bar to specify participants’ location
• Built-in reverse feature to flip mirrored image
• Wide Compatibility: Zoom™, Facebook™ Messenger, Skype™, Microsoft Teams™, etc.
-
System Requirements
- • Available USB-C™ or USB™ Type-A port
- • UVC 1.1 & UAC 1.0 support
- • Windows® 10 / 8.1
- • macOS® 10.14.11 or later with UVC support
- • Chrome OS™ with UVC support
- • Linux® (special configuration required)
Hardware Warranty
1-year limited warranty
Host Connector
USB-C® / USB™ 2.0 Type-A
Image Sensor
1/2.9” CMOS Sensor
Shutter Style
N/A Privacy Cover
No
Protocol
UVC 1.1 & UAC
Operating Voltage & Current
DC5V/500 mA ±15 mA
Mounting Style
N/A
LED Indicator
Red: Muted
Blue: Power onPerformance Effective Pixels
Full Screen Mode:
1920(H) x 540(V)
360° All Around View Mode:
1920(H) x 720(V)
Host Mode:
1920(H) x 270(V), 1920(H) x 810(V)
Dual Host Mode:
1920(H) x 270(V), 960(H) x 810(V)
Single View Mode:
1920(H) x 1080(V)
Wide Angle View Mode:
120°(H), 88.6°Megapixels
2 million pixels (2MP)
Output Format
MJPEG
Frame Rate
30 FPS
Display Output Supported Resolutions
1920 x 1080
1280 x 720
640 x 480 / 360Display FOV
Full Screen Mode:
2 - 180°(H), 53°(V)
360° All Around View Mode:
360°(H), 53°(V),
Host Mode:
360°(H) , 120°(H), 53°(V)
Dual Host Mode:
360°(H) , 60°(H), 53°(V)
Single View Mode:
90°(H), 58.5°(V)
Wide Angle View Mode:
120°(H), 88.6°Maximum Display Refresh Rate
30 Hz
Microphone
Built-in omnidirectional microphone
Physical Specifications Color
White, Black
Enclosure Type
ABS
Lens Kit
N/A
Cable Length
9.84 ft. (300 cm)
Product Height
7.6 in. (19.3 cm)
Product Width
3.68 in. (9.35 cm)
Product Depth
1.46 in. (3.7 cm)
Product Weight
≒12.35 oz (350g)
Storage Temperature
–4°F to 140°F (-20°C to 60°C)
Storage Humidity
< 90% non-condensing
Operating Temperature
41°F to 104°F (0°C to 40°C)
Operating Humidity
< 90% non-condensing
Package Contents- • 1 - JVCU360 360° All Around Webcam
- • 1 - Quick Installation Guide
