About the item
- Uncompressed 1080p60 capture reduces CPU load
- Power Delivery 3.0 lets you stream live without interruption
- Professional listening and live audio mixing with built-in audio mixer
- Full HD video and audio high-performance record/playback through USB-C® 3.1
- Easily mount your preferred camera with the cold shoe adapter
- UVC standard - No driver installation required
- Field production made easy with its compact size
Specifications
| Category | Specification |
|---|---|
| Hardware | |
| Audio Input | 1 - 3.5mm AUX |
| Audio Output | 1 - 3.5mm AUX |
| Audio Switcher | Yes |
| Host Connector | 1 - USB-C® 3.1 Female |
| Ports | 1 - USB-C® 3.1 Gen 1 (Host) |
| 1 - USB-C® PD 3.0 | |
| 1 - HDMI™ Input | |
| 1 - 3.5mm AUX Audio Out | |
| 1 - 3.5mm AUX Mic In | |
| Power Source | Bus-powered or self-powered (USB-C® PD power) |
| Video Input | 1 - HDMI™ Female |
| Video Output | N/A |
| Video Switcher | N/A |
| Warranty | 2 Year Limited |
| Performance | |
| Audio Channel | 2.1 via HDMI™ |
| Audio Frequency | 48 kHz |
| Compressions | USB™ 3.0: MJPEG/YUV 4:2:2 |
| USB™ 2.0: MJPEG | |
| Encode Format | MP4, MJPEG, H.264 / AVC + AACX |
| HDR Supported | N/A |
| Headset | 2.1 Stereo |
| Max Display Refresh Rate | 60 Hz |
| Microphone | Stereo microphone supported |
| 24-bit sigma-delta ADC | |
| Supported Resolution - Input | 1920 x 1080 |
| Supported Resolution - Output | N/A |
| Power | |
| Input Current | 3A |
| Input Voltage | 20V |
| Output Current | 3A |
| Output Voltage | 20V |
| Power Consumption | ≤ 280 mA |
| Power Delivery | Up to 60W via USB-C® |
| Physical Specifications | |
| Cable Length | 3.3 ft (1m) |
| Color | Black |
| Enclosure Type | Aluminum |
| Operating Humidity | < 80% non-condensing |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Product Depth | 0.69 in (17.5 mm) |
| Product Height | 2.54 in (64.5 mm) |
| Product Weight | 5.03 oz (142.5 g) |
| Product Width | 5.27 in (133.8 mm) |
| Storage Humidity | < 85% non-condensing |
| Storage Temperature | 14 to 149°F (-10 to 65°C) |
| Package Contents | |
| 1 - JVA02 Live Capture Adapter | |
| 1 - USB-C® 2.0 to USB-C® cable | |
| 1 - USB-C® 3.0 to USB™ Type-A cable | |
| 2 - Cold shoe adapters | |
| 1 - Quick Installation Guide |
