About This Product
The JVU430 USB™ 4K Ultra HD Webcam delivers smooth Ultra HD and HD video, highlighting subtle details of movements and expressions. Perfect for everyday use, the JVU430 features dual microphones, and a security camera image sensor that automatically adjusts to suit different lighting conditions — everything you need to look and sound your best during video calls. The webcam has a 360-degree swivel design to make calls from any angle, and also has a built-in privacy cover for when the camera is not in use. The JVU430 is equipped with a USB-C™ cable and a USB™ Type-A connector to work with both your older and newer devices.
Features
• Supports MJPEG image formats
• Ultra HD 4K image 8MP sensor with wide angle lens
• Supports 4K @ 30 FPS and 1080P @ 60 FPS
• 94° field of view with nearly zero distortion
• Built-in high-fidelity dual microphones
• Ultra-low illumination F/2.0 aperture lens for enhanced light sensitivity
• Privacy cover
• Compliant with standard UVC 1.1/1.5 & UAC 1.0 protocol, driver-free
• Wide Compatibility: Zoom™, Facebook™ Messenger, Skype™, Microsoft Teams™, etc.
System Requirements
- • Available USB-C® or USB™ Type-A port
- • UVC 1.1/1.5 & UAC 1.0 support
- • Windows® 10 / 8.1
• macOS® with UVC support
• Chrome OS™ with UVC support
• Linux® (special configuration required)
| Hardware | |
|
Warranty |
1-year Limited |
|
Host Connector |
USB-C® / USB™ 2.0 Type-A |
|
Image Sensor |
1/2.5” CMOS Sensor |
|
Shutter |
Electronic Rolling Shutter |
|
Privacy Cover |
Yes |
|
Protocol |
UVC 1.0/1.1/1.5 & UAC |
|
Operating Voltage & Current |
DC 5V/3500 mA ±15 mA |
|
Mounting Style |
Monitor clamp mount and tripod mount |
|
LED Indicator |
White/Green: Power on |
| Performance | |
|
Effective Pixels |
3840(H) × 2160(V) |
|
Megapixels |
8 |
|
Output Format |
MJPEG, YUV2 |
|
Frame Rate |
2160P/ 1080P/ 720P/ 540P/ 480P/ 360P at 30FPS |
|
Display Output Supported Resolutions |
MJPEG: |
|
Display FOV |
94° (Horizontal : 87°) |
|
Maximum Display Refresh Rate |
60 Hz |
|
Microphone |
Dual High-fidelity Stereo Mic |
| Physical Specifications | |
|
Color |
Black and Silver |
|
Enclosure Type |
ABS (Housing)/PC (Panel)/optical plastic |
|
Lens Kit |
PC+30% GF (Housing)/Glass + COC (Lens) |
|
Cable Length |
6.56 ft (200 cm) |
|
Product Height |
2.54 in. (6.46 cm) |
|
Product Width |
4.17 in. (10.6 cm) |
|
Product Depth |
2.5 in. (6.36 cm) |
|
Product Weight |
≒215 g |
|
Storage Temperature |
–4°F to 140°F (-20°C to 60°C) |
|
Storage Humidity |
< 90% non-condensing |
|
Operating Temperature |
32°F to 104°F (0°C to 60°C) |
|
Operating Humidity |
< 90% non-condensing |
Package Contents
- • 1 - JVU430 USB™ 4K ULTRA HD Webcam
- • 1 - Quick Installation Guide
