About This Product
Our USB-C® to HDMI™ 2.1 8K Adapter allows you to conveniently connect your gaming laptop, MacBook®, Chromebook™, or tablet to an 8K UHD / 4K 144Hz external monitor, 8K UHDTV, projector and other display device using an HDMI™ input.
This adapter offers the latest USB-C® to 8K or 4K 144Hz HDMI™ connection, letting you hook up an HDMI™ display to a gaming laptop, tablet, or phone that supports DisplayPort™ Alternate Mode for a plug and play connection.
Features
- • This adapter supports HDMI™ 2.1 allowing for resolutions up to 8K for gamers and professionals that need the highest resolution.
- • Connect a USB-C® port with DP™ 1.4 Alt Mode protocol (compatible with DP™ 1.2 Alt Mode) enabled host devices to get 8K video to HDMI™ 2.1 (compatible with HDMI™ 2.0/1.4) enabled TVs for display
- • Compliant with HDMI™ 2.1 specifications
- ⚬ With DSC: 8K @ 60 Hz or 4K @ 144 Hz
- ⚬ Without DSC: 8K @ 30 Hz or 4K @ 120 Hz
- • Supports 8K High Dynamic Range (HDR)
- • RGB light indicator for gaming setups
- • Ideal accessory for Windows® laptops, MacBook®, and Chromebook™ computers with a USB-C® port
- • 3.94-inch (10 cm) high quality USB-C® cable
- • No driver installation required
Specifications
System Requirements
- • Available USB-C® port that supports DisplayPort™ Alt Mode
- • GPU and video source must support DisplayPort™ 1.4 with DSC to achieve 8K @ 60 Hz /4K @ 144 Hz resolution
Special Notes
- • The resolution may be limited to 4K @ 60 Hz with macOS® and iOS® devices.
|
Hardware |
|
|
Warranty |
2 Year Limited |
|
Host Connector |
USB-C® Male (DP™ 1.4 Alt Mode) |
|
Video Output |
HDMI™ 2.1 Female |
|
Power Source |
Bus-Powered |
|
Audio Supported |
Yes |
|
USB™ Pass-Through |
N/A |
|
Ports |
1 – HDMI™ |
|
Performance |
|
|
Maximum Display Resolution |
With DSC: Without DSC: |
|
Maximum Display Refresh Rate |
144 Hz |
|
Displays Supported |
Yes |
|
Wide Screen Supported |
Yes |
|
Audio Channel |
2.1 via HDMI™ |
|
Power |
|
|
Power Delivery |
N/A |
|
Power Consumption |
N/A |
|
Physical Specifications |
|
|
Color |
Space Gray/Black |
|
Enclosure Type |
Aluminum/ Plastic |
|
Cable Length |
3.94 in. (100 mm) |
|
Product Height |
2.75 in. (70mm) |
|
Product Width |
0.8 in. (20.5 mm) |
|
Product Depth |
0.41 in. (10.45 mm) |
|
Product Weight |
0.88 oz (28g) |
|
Storage Temperature |
14 to 160°F (-10 to 71°C) |
|
Storage Humidity |
< 85% non-condensing |
|
Operating Temperature |
32 to 113°F (0 to 45°C) |
|
Operating Humidity |
< 85% non-condensing |
Package Contents
- • 1 - USB-C® to HDMI™ 2.1 8K Adapter (JCA157)
- • 1 - Quick Installation Guide (QIG)
