| Processor |
|
| Processor Family |
13th Generation Intel® H Series Core i5 / i7 Processor |
| Processor Options |
|
| Core i5-13420H |
8 Cores (4 P-core + 4 E-core), 12 Threads, Base: P-core 2.1GHz / E-core 1.5GHz, Max: P-core 4.6GHz / E-core 3.4GHz, 12MB Cache, Intel® UHD Graphics |
| Core i7-13620H |
10 Cores (6 P-core + 4 E-core), 16 Threads, Base: P-core 2.4GHz / E-core 1.8GHz, Max: P-core 4.9GHz / E-core 3.6GHz, 24MB Cache, Intel® UHD Graphics |
| Operating System |
Windows® 11 Pro, Windows® 11 Home, Windows® 11 Home Single Language, Windows® 11 Home Single Language in S mode, Windows® 11 Home in S mode, No preload OS |
| Graphics |
|
| GPU |
Intel® UHD Graphics (Integrated, Shared Memory) |
| TGP |
Shared CPU TDP |
| Key Features |
DirectX® 12.1 |
| Monitor Support |
Supports up to 3 displays (1 native + 2 external) |
| HDMI |
Up to 4K@30Hz |
| USB-C Display Output |
Up to 4K@60Hz |
| Chipset |
Intel® SoC (System on Chip) platform |
| Memory |
|
| Max Memory |
8GB / 16GB (soldered, not upgradable) |
| Memory Type |
LPDDR5-4800 |
| Memory Slots |
No slots, single-channel (8GB) / dual-channel (16GB) |
| Storage |
|
| Storage Support |
One M.2 PCIe® 4.0 x4 slot, Up to 1TB SSD |
| Storage Type |
PCIe® NVMe®, PCIe® 4.0 x4 (256GB / 512GB / 1TB) |
| Removable Storage |
SD card reader |
| Multimedia |
|
| Audio Chip |
High Definition (HD) Audio |
| Speakers |
Stereo speakers, 1.5W x2, Dolby Audio™ |
| Microphone |
Dual-microphone array |
| Camera Options |
FHD 1080p with privacy shutter, HD 720p with privacy shutter |
| Battery and Power |
|
| Battery |
47Wh Li-Polymer, Rapid Charge Boost (2 hrs runtime in 15 min) |
| Max Battery Life |
MobileMark® 2018: 8 hrs, 1080p playback: 12 hrs |
| Power Adapter |
65W round tip (3-pin), 100-240V, 50-60Hz |
| Display |
|
| Display Options |
|
| 15.6" FHD (1920x1080) TN |
250nits, Anti-glare, 16:9, 400:1 contrast, 45% NTSC, 45° / 45° / 15° / 35° viewing angles |
| 15.6" FHD (1920x1080) IPS |
300nits, Anti-glare, 16:9, 800:1 contrast, 45% NTSC, 85° / 85° / 85° / 85° viewing angles |
| 15.6" FHD (1920x1080) Touch IPS |
300nits, Anti-glare, 16:9, 800:1 contrast, 45% NTSC, 85° / 85° / 85° / 85° viewing angles |
| Input Devices |
|
| Pen |
No support |
| Keyboard |
6-row, multimedia Fn keys, numeric keypad |
| Keyboard Backlight |
LED-backlit / Non-backlit |
| Touchpad |
Mylar® surface, multi-touch, 69 x 104 mm, Precision TouchPad (PTP) |
| Design & Build |
|
| Dimensions (WxDxH) |
359.3 x 235 x 17.9 mm (14.15 x 9.25 x 0.70 inches) |
| Weight |
Starting at 1.62 kg (3.57 lbs) |
| Case Colors |
Abyss blue, Arctic grey, Frost blue |
| Surface Treatment |
IMR (In-Mold Decoration by Roller) |
| Case Material |
PC-ABS (top & bottom) |
| Connectivity |
|
| Ethernet |
No onboard Ethernet |
| WLAN + Bluetooth Options |
Wi-Fi® 5 (802.11ac 2x2) + Bluetooth® 5.1 OR Wi-Fi® 6 (802.11ax 2x2) + Bluetooth® 5.2 |
| WWAN |
No support |
| Ports |
|
| USB |
2x USB 3.2 Gen 1, 1x USB-C® 3.2 Gen 1 (Data, Power Delivery, DisplayPort™ 1.2) |
| HDMI |
1x HDMI® 1.4 |
| Audio Jack |
1x Headphone/microphone combo (3.5mm) |
| Card Reader |
1x SD Card Reader |
| Power Connector |
1x Power Connector |
| Docking Support |
USB-C® docking solutions available |
| Security & Privacy |
|
| Security Chip |
Firmware TPM 2.0 (integrated in SoC) |
| Fingerprint Reader |
Touch style (integrated in power button) / No fingerprint reader |
| BIOS Security |
Administrator password, Power-on password, Hard disk password, Self-healing BIOS |
| Camera Privacy |
Camera privacy shutter |
| Warranty |
|
| Base Warranty Options |
1-year courier/carry-in, 2-year system board warranty (Korea only), 2-year (1-yr battery) courier/carry-in, 3-year (1-yr battery) courier/carry-in |
