| P/N | CA-1X6-00F1WN-00 |
| SERIES | CTE |
| CASE TYPE | Full Tower |
| DIMENSION (H X W X D) | 565.2 x 327 x 599.2 mm |
| (22.25 x 12.87 x 23.59 inch) | |
| NET WEIGHT | 16.7 kg / 36.82 lbs. |
| PANEL | 4mm Tempered Glass x 1 |
| COLOR / MATERIAL | Black / SPCC + ABS |
| Warranty | 1 Year |
| COOLING SYSTEM | Front(intake): 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1 |
| Top(exhaust): | |
| 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1 | |
| Rear(intake): | |
| 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1 | |
| DRIVE BAYS | 7 x 3.5 or 12 x 2.5 |
| EXPANSION SLOTS | 7 |
| MOTHERBOARDS | 6.7î x 6.7 (Mini ITX), 9.6 x 9.6 (Micro ATX), |
| 12 x 9.6 (ATX), 12 x 13 (E-ATX) | |
| I/O PORT | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 4, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: |
| 3 x 120mm, 2 x 120mm, 1 x 120mm | |
| 3 x 140mm, 2 x 140mm, 1 x 140mm | |
| 2 x 200mm, 1 x 200mm |
|
| Top: | |
| 2 x 120mm, 1 x 120mm | |
| 2 x 140mm, 1 x 140mm | |
| Right (M/B Side): | |
| 3 x 120mm, 2 x 120mm, 1 x 120mm | |
| 3 x 140mm, 2 x 140mm, 1 x 140mm |
|
| Rear: | |
| 3 x 120mm, 2 x 120mm, 1 x 120mm |
|
| 3 x 140mm, 2 x 140mm, 1 x 140mm | |
| 2 x 200mm, 1 x 200mm | |
| Bottom: | |
| 3 x 120mm, 2 x 120mm, 1 x 120mm | |
| 3 x 140mm, 2 x 140mm, 1 x 140mm | |
| RADIATOR SUPPORT | Front: |
| 1 x 360mm, 1 x 240mm, 1 x 120mm |
|
| 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm | |
| Top: | |
| 1 x 240mm, 1 x 120mm | |
| 1 x 140mm | |
| Right (M/B Side): | |
| 1 x 360mm, 1 x 240mm, 1 x 120mm | |
| 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm | |
|
Rear: |
|
| 1 x 360mm, 1 x 240mm, 1 x 120mm |
|
| 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm | |
| Bottom: | |
| 1 x 360mm, 1 x 240mm, 1 x 120mm |
|
| 1 x 280mm, 1 x 140mm | |
| CLEARANCE | CPU cooler max height: |
| 190mm |
|
| VGA max length: | |
| 370mm (With radiator) | |
| 420mm (Without radiator) |
|
| PSU max length: | |
| 220mm |
*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
