Feature Highlights:
-
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- 8-Pin PCIe power connector
- ITX-Ready ultra-compact Graphics Card
- Fits in 99% of PC builds
- BladeLink Fan
- All-new FireStorm Utility
- Warranty : 3 years + Additional 2 years after Registration
Specifications:
| Specification | Details |
|---|---|
| GPU | NVIDIA GeForce RTX 5060 |
| CUDA Cores | 3840 |
| Video Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Engine Clock | 2497 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 3 × DisplayPort 2.1b (UHBR20), 1 × HDMI 2.1b |
| DisplayPort Support | Up to 4K @ 480Hz or 8K @ 165Hz with DSC |
| HDMI Support | Up to 4K @ 480Hz HDR or 8K @ 120Hz HDR with DSC, Gaming VRR |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display |
| Recommended PSU | 550W |
| Power Consumption | 145W |
| Power Input | 1 × 8-pin |
| DirectX Support | Microsoft DirectX® 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling | Air Cooled |
| Slot Size | 2-slot |
| SLI Support | No |
| Supported OS | Windows 11 / 10 64-bit (v1809 or later) |
| Card Dimensions | 164.5 × 111.2 × 36.4 mm (6.5" × 4.4" × 1.4") |
| Accessories | User Manual |
