Feature Highlights:
-
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- 8-Pin PCIe power connector
- White LED lighting
- SFF-Ready Graphics Card
- Compact dual-fan form factor
- IceStorm 2.0 Cooling
- BladeLink Fans
- FREEZE Fan Stop
- Metal Backplate
-
Warranty: 3 Years + Additional 2 years after Registration
Specifications
| Category | Specification |
|---|---|
| GPU | NVIDIA GeForce RTX 5060 Ti |
| CUDA Cores | 4608 |
| Video Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Engine Clock | 2632 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 3 × DisplayPort 2.1b (UHBR20)1 × HDMI® (2.1b) |
| DisplayPort Capabilities | Up to 4K 480Hz or 8K 165Hz (with DSC) |
| HDMI Capabilities | 4K 120Hz HDR, 8K 60Hz HDR, VRR |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display |
| Recommended Power Supply | 600W |
| Power Consumption | 180W |
| Power Input | 1 × 8-pin connector |
| DirectX Support | Microsoft DirectX® 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling | IceStorm 2.0 |
| Slot Size | 2-slot |
| SLI Support | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 or later) |
| Card Dimensions | 220.5 × 120.25 × 41.6 mm (8.7" × 4.7" × 1.6") |
| Accessories | User Manual |
