Feature Highlights:
-
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- IceStorm 3.0 Advanced Cooling
- 34% Larger Vapor Chamber
- BladeLink Fans
- Reinforced Metal Mid-Frame
- FREEZE Fan Stop, Active Fan Control 2.0, Dual BIOS
- SPECTRA 2.0 RGB Lighting
- SPECTRA LINK Lighting Sync port
- Metal die-cast Backplate
- Bundled with GPU Support Bracket
- 12V-2x6 Safety Light
- All-new FireStorm Utility
Specifications:
| Specification | Details |
|---|---|
| GPU | NVIDIA GeForce RTXâ„¢ 5090 |
| CUDA® Cores | 21760 |
| Video Memory | 32GB GDDR7 |
| Memory Bus | 512-bit |
| Engine Clock | 2407 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x16 |
| Display Outputs | - 3 × DisplayPort 2.1b with UHBR20 (Supports up to 4K 480Hz or 8K 165Hz with DSC) - 1 × HDMI 2.1b (Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate) |
| HDCP Support | 2.3 |
| Multi-Display Capability | Quad Display |
| Recommended Power Supply | 1000W (High power consumption, please carefully read your PSU manual before installation.) |
| Power Consumption | 575W |
| Power Input | 1 × 12V-2x6 power input |
| DirectX | Microsoft DirectX® 12 Ultimate |
| OpenGL | 4.6 |
| Cooling | IceStorm 3.0 |
| Slot Size | 3.5 |
| SLI | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 November 2018 or later) |
| Card Dimensions | 329.7mm × 137.8mm × 67.8mm (13" × 5.4" × 2.7") |
| Accessories | - User Manual - 4 × 8-pin-to-16-pin cable - SPECTRA LINK cable - GPU Support Stand |
| Warranty | 3 years + Additional 2 years after Registration |
