Feature Highlights:
-
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- IceStorm 3.0 Advanced Cooling
- 34% Larger Vapor Chamber
- BladeLink Fans
- Reinforced Metal Mid-Frame
- FREEZE Fan Stop, Active Fan Control 2.0, Dual BIOS
- SPECTRA 2.0 RGB Lighting
- SPECTRA LINK Lighting Sync port
- Metal die-cast Backplate
- Bundled with GPU Support Bracket
- 12V-2x6 Safety Light
- All-new FireStorm Utility
-
Warranty: 3 Years + Additional 2 years after Registration
Specification
| Category | Specification |
|---|---|
| GPU | NVIDIA® GeForce RTX™ 5090 |
| CUDA Cores | 21,760 |
| Video Memory | 32GB GDDR7 |
| Memory Bus | 512-bit |
| Memory Clock | 28 Gbps |
| Engine Clock | 2422 MHz |
| Bus Interface | PCI Express 5.0 x16 |
| Display Outputs | 3x DisplayPort 2.1b with UHBR201x HDMI 2.1b (4K 480Hz / 8K 120Hz HDR, VRR) |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display (4 monitors) |
| Max Resolution | 4K at 480Hz or 8K at 165Hz with DSC |
| Recommended PSU | 1000W |
| Power Consumption | 575W ⚠️ High power draw – ensure PSU compatibility |
| Power Input | 1x 12V-2x6 Connector |
| DirectX Support | Microsoft DirectX® 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling System | IceStorm 3.0 |
| Slot Size | 3.5-slot |
| SLI Support | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 or later) |
| Card Dimensions (L Ă— W Ă— H) | 329.7 Ă— 137.8 Ă— 67.8 mm (13" Ă— 5.4" Ă— 2.7") |
| Accessories Included |
- User Manual -4x 8-pin to 16-pin Cables -SPECTRA LINK Cable -GPU Support Stand |
